2022 CAT D3 LGP for Sale in Southampton, UK

CAT D3 LGP Weight: 9,693 KGS Hours: 3015 HP: 104
ENGINE
Blow by- Minimal- - - -
Knocking- No knocking- - - -
Air cleaners- good- - - -
Any smoke- no smoke- - - -
Oil or fuel leaks- No leaks- - - -
General running condition- Runs well- - - - - - - TRANSMISSION
Gear change- HST works well- - - -
Steering- Responsive- - - -
Oil leaks- No leaks- - - -
Is the transmission noisy?- No- - - -
Controls- Good controls- - - -
General running condition- Moves well- - - - - - - UNDERCARRIAGE
Shoe width- 660mm- - - -
Shoe height- 50mm, 95%- - - -
Shoes - any wear in trailing edge?- Minimal- - - -
Rail height- 100mm, 75%- - - -
Any signs of link failure- No- - - -
Average diameter of pins and bushings- 55mm, 75%- - - -
Have pins been turned on chains?- No- - - -
Sprockets- 75mm gape, 15mm tips- - - - - - - IDLERS - UNDERCARRIAGE
Left side front idler- 50mm x 20mm, 75%- - - -
Right side front idler- 50mm x 20mm, 75%- - - - - - - TOP ROLLERS - UNDERCARRIAGE
Left side top roller- 143mm x 141mm, 60%- - - -
Right side top roller- 143mm x 140mm, 60%- - - - - - - BOTTOM ROLLERS - UNDERCARRIAGE
Roller 1- 156mm x 153mm, 40%- - - -
Roller 2- 156mm x 155mm, 40%- - - -
Roller 3- 156mm x 152mm, 40%- - - -
Roller 4- 155mm x 151mm, 40%- - - -
Roller 5- 160mm x 148mm, 40%- - - -
Roller 6- Visual only, 40%- - - -
Roller 7- Visual only, 40%- - - - - - - CAB
Cab mounts - any wear- Good mounts- - - -
Any wiring for laser system- Yes- - - -
Back up alarm- Loud and clear- - - -
Battery isolator switch- Manual fitted- - - -
Lights- All working- - - -
Wipers- All working- - - -
Wipers- All working- - - -
Heater- Good heat- - - -
A/C- Nice and cold- - - -
Seat condition- Good condition, all working- - - -
Cladding condition- Good condition- - - -
Floor mat condition- No wear or tears- - - -
Seat belt- Working as should- - - -
Mirrors- Rear view only- - - -
Cab mounts- Good mounts- - - -
Cab glass condition- Some wiper scuffs- - - -
Cab glass, any cracks- No- - - -
Any perspex fitted- none fitted- - - -
Steps and grab handles secure?- Fitted secure, no damage- - - - - - - BLADE
Blade type- PAT blade- - Blade width- 3210mm- - Blade height- 1030mm- - Main lift rams, wear- L/H: 2mm x 1mm, R/H: 1mm x 1mm- - Pitch ram, wear- L/H: 3mm x 5mm, R/H: 3mm x 5mm- - Tilt ram, wear- 5mm x 3mm- - Link ram, wear- 2mm x 2mm- - Ball joint, wear- Trunnion and bearings to be replaced- - C Frame, wear- 3mm x 3mm- - Face / moldboard- In good shape- - - -
Cutting edges condition- 25mm- - - -
Have cutting edges been turned?- No- - - - - - - PAINT & DECALS
Any damage to panels- RH engine panel damaged- - - -
Paint condition- Reasonable- - - -
Any areas repainted- No- - - -
Any rust patches- Nothing major- - - -
Condition of decals- Good- - - - - - - DIMENSIONS- Length
Width
Height- Measurements with blade straight- 4250mm
3215mm
2900mm- Measurements with blade turned- 4890mm
2900mm
2900mm- Measurement from outside to outside of tracks-
2415mm- - Measurements with blade straight- Length: 4250mm
Width: 3215mm
Height: 2900mm- Measurements with blade turned- Length: 4890mm
Width: 2900mm
Height: 2900mm- Measurement from outside to outside of tracks- Length:
Width: 2415mm
Height:
